Pagination

Oct 3, 2025 | Glynn Bird

SDKs Pagination

Cloudant has several multi-document APIs including:

POST /{db}/_all_docs - extract data from the primary index.
POST /{db}/_find - query data within documents, backed by secondary indexes.
POST /{db}/_design/{ddoc}/_search/{index} - search for data indexed with an Apache Lucene index.
POST /{db}/_design/{ddoc}/_view/{view} - query a MapReduce view.
Plus all of the above operating on a single partition in a partitioned Cloudant database.

Each of these APIs supports pagination, but different techniques are required depending on the API. Sometimes its skip/limit, sometimes startkey/endkey, sometimes a bookmark is required.

Now the Cloudant SDKs now include a (Beta) pagination feature which presents a unified API for paging through result sets, iterating by page or by row.

One API for paging through any of the multi-document endpoints.
Automatic handling of bookmarks and key range calculations.
Consume documents piecemeal or in batches.
Uniformity with other IBM Cloud SDKs.

pagination

Photo by Patrick Tomasso on Unsplash

In this blog post we’ll present some sample code for using the pagination API with each of the multi-document API calls.

⚠️ Note: the pagination API can chain multiple queries together in quick succession - enough successive API calls to exhaust small Cloudant plans of their query quota so that some calls could produce a HTTP 429 response. Please ensure that your Cloudant plan is large enough to be able to cope with the query rate. Alternatively a delay between iterations may be necessary.

All docs🔗

The paginator can page through the entire primary index:

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // instantiate the Cloudant client, using credentials
  // stored in environment variables
  const client = CloudantV1.newInstance()

  // create a pagination to page through all documents
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_ALL_DOCS,
    {
      db: 'pagetest'
    }
  )

  // iterate through the pages
  for await (const page of pagination.pages()) {
    console.log('page', page.length, 'first doc id', page[0].id)
  }
}

main()

or a range of documents defined by a start and end key:

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // instantiate the Cloudant client, using credentials
  // stored in environment variables
  const client = CloudantV1.newInstance()

  // create a pagination to page through all documents
  // in pages of 200, starting from a known document
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_ALL_DOCS,
    {
      db: 'pagetest',
      startKey: '000xuZn',
      endKey: '0017UoL'
    }
  )

  // iterate through the pages
  for await (const page of pagination.pages()) {
    console.log('page', page.length, 'first doc id', page[0].id)
  }
}

main()

The third parameter of Pagination.newPagination defines the options made during the Cloudant request:

Add includeDocs: true to bring back the associated document body.
Omit startkey/endKey to iterate through the entire primary index.

An alternative syntax is to use the “pager” which is similar to other IBM Cloud SDKs:

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // Instantiate Cloudant client using environment credentials
  const client = CloudantV1.newInstance()

  // create a pagination to page through all documents
  // in pages of 200, starting from a known document
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_ALL_DOCS,
    {
      db: 'pagetest',
      startKey: '000xuZn',
      endKey: '0017UoL'
    }
  )

  // use the pager syntax
  const pager = pagination.pager()

  do {
    const page = await pager.getNext()
    console.log(page.length, 'first doc id', page[0].id)
  } while(pager.hasNext())
}

main()

Cloudant Query🔗

The same syntax can be used to perform Cloudant Query API calls where a selector defines the slice of data being queried:

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // instantiate the Cloudant client, using credentials
  // stored in environment variables
  const client = CloudantV1.newInstance()

  // create a pagination to page through all documents
  // in pages of 200, starting from a known document
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_FIND,
    {
      db: 'pagetest',
      limit: 200,
      selector: {
        team: 'white'
      },
      fields: ['_id', 'name']
    }
  )

  // iterate through the pages
  for await (const page of pagination.pages()) {
    console.log('page', page.length, 'first doc id', page[0]._id)
  }
}

main()

Note: it is important that a secondary index is available to support the query otherwise the pagination queries will become progressively less efficient and slower with each invocation. In this case we need an index on team to support a query for documents matching the selector { team: 'white' }. See https://blog.cloudant.com/2020/05/20/Optimising-Cloudant-Queries.html.

As well as returning pages of data (which map to underlying API queries) we may also paginate through each returned document instead:

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // Instantiate Cloudant client using environment credentials
  const client = CloudantV1.newInstance()

  // create a pagination to page through all documents
  // in pages of 200, starting from a known document
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_FIND,
    {
      db: 'pagetest',
      selector: {
        team: 'white'
      },
      fields: ['_id', 'name']
    }
  )

  // iterate through the returned rows (documents)
  for await (const row of pagination.rows()) {
    console.log('row', row)
  }
}

main()

Cloudant Search🔗

With a suitable Cloudant Search index, search results sets can be paginated. In this case we need to supply the design document name (ddoc), the index defined in that design document (index) and the Lucene query to execute (query):

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // Instantiate Cloudant client using environment credentials
  const client = CloudantV1.newInstance()

  // create a pagination to page through a search result set
  // for documents whose team is white and who were born
  // in the 1980s or 19990s
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_SEARCH,
    {
      db: 'pagetest',
      query: 'team:white AND dob:[1980-01-01 TO 2000-01-01]',
      includeDocs: true,
      ddoc: 'searchddoc',
      index: 'searchByTeamDob'
    }
  )

  // iterate through the pages
  for await (const page of pagination.pages()) {
    console.log('page', page.length, 'first doc id', page[0].doc._id)
  }
}

main()

Cloudant Views (MapReduce)🔗

MapReduce view results can be paginated too. We need to pass in the design document name (ddoc) and the view name defined in the design document (view):

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // Instantiate Cloudant client using environment credentials
  const client = CloudantV1.newInstance()

  // create a pagination to page through a view keyed on
  // the documents' team/dob pair. In this case we only
  // want documents in team='white'
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_VIEW,
    {
      db: 'pagetest',
      includeDocs: true,
      startKey: ["white"],
      endKey: ["white",{}],
      ddoc: 'viewddoc',
      view: 'byTeamAndDob',
      reduce: false
    }
  )

  // iterate through the pages
  for await (const page of pagination.pages()) {
    console.log('page', page.length, 'first doc id', page[0]._id)
  }
}

main()

As an alternative to paginating by batches or rows, we can create a stream of results, suitable to piping to the console or to a file:

import { Transform } from 'node:stream';
import { pipeline } from 'node:stream/promises'
import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // Instantiate Cloudant client using environment credentials
  const client = CloudantV1.newInstance()

  // create a pagination to page through a view keyed on
  // the documents' team/dob pair. In this case we only
  // want documents in team='white'
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_VIEW,
    {
      db: 'pagetest',
      includeDocs: true,
      startKey: ["white"],
      endKey: ["white",{}],
      ddoc: 'viewddoc',
      view: 'byTeamAndDob',
      reduce: false
    }
  )

  // create a stream transformer
  const myTransform = new Transform({
    objectMode: true,
    transform(obj, encoding, callback) {
      // transform the object into a CSV
      const str = `${obj.doc.name},${obj.doc.email}\n`
      this.push(str)
      callback()
    },
  });

  // use the streaming syntax
  const rowStream = pagination.rowStream()

  // create a pipeline: rowStream --> myTransform ---> stdout
  await pipeline(rowStream, myTransform, process.stdout)
}

main()

Partitioned operations🔗

In addition to the global “all_docs”, Cloudant Query, Cloudant Search and View support, all of the partitioned variations of these APIs also support pagination. We need to supply a pager type of:

PagerType.POST_PARTITION_FIND for partitioned Cloudant Query calls.
PagerType.POST_PARTITION_ALL_DOCS for partitioned all_docs calls.
PagerType.POST_PARTITION_SEARCH for partitioned Cloudant Search calls.
PagerType.POST_PARTITION_VIEW for partitioned MapReduce calls.

and all operations require a partition key as a partitionKey parameter:

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // instantiate the Cloudant client, using credentials
  // stored in environment variables
  const client = CloudantV1.newInstance()

  // create a pagination to page a single partition's
  // documents finding documents where the total > 10.
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_PARTITION_FIND,
    {
      db: 'pagetest2',
      partitionKey: '50',
      limit: 20,
      selector: { total: { "$gt": 10 }}
    }
  )

  // iterate through the pages
  for await (const page of pagination.pages()) {
    console.log('page', page.length, 'first doc id', page[0]._id)
  }
}

main()

or using the “pager” syntax:

import { CloudantV1, PagerType, Pagination } from '@ibm-cloud/cloudant'

async function main() {
  // Instantiate Cloudant client using environment credentials
  const client = CloudantV1.newInstance()

  // create a pagination to page a single partition's
  // documents finding documents where the total > 10.
  const pagination = Pagination.newPagination(
    client,
    PagerType.POST_PARTITION_FIND,
    {
      db: 'pagetest2',
      partitionKey: '50',
      selector: { total: { "$gt": 10 }}
    }
  )

  // use the pager syntax
  const pager = pagination.pager()

  do {
    const page = await pager.getNext()
    console.log(page.length, 'first doc id', page[0]._id)
  } while(pager.hasNext())
}

main()

Other languages🔗

In addition to Node.js, pagination APIs are available for Java, Python and Go.

Limitations🔗

Note the limitations outlined in the documentation.
